• UL and CSA Listed, Meeting NEMA MG1 standards.
• Brush holder design provides easy access for motor maintenance.
• Permanent magnet design ensures higher motor efficiency.
• Permanently lubricated sealed bearings extend the lifetime of the motor.
• Compatible with PWM or SCR type controllers.
• LEESON® motors. Motors and solutions at our core™

Nameplate Specifications

Output HP	0.33 Hp
Output KW	0.25 kW
Voltage	24 V
Speed	1800 rpm
Service Factor	1.0
Frame	S56C
Enclosure	Totally Enclosed Non Ventilated
Thermal Protection	No Protection
Efficiency	70.3 %
Ambient Temperature	40 °C
Current	13.5 A
Duty	Continuous
Insulation Class	F
Drive End Bearing Size	6203
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	N

Technical Specifications

Rotation	Reversible
Mounting	Rigid C base
Overall Length	10.77 in
Frame Length	4.47 in
Shaft Diameter	0.625 in
Shaft Extension	2.06 in
Torque	11.7 LB-IN

General Specifications

UPC	691720006733
Weight	25.00 LB
Packaged Length	14.44 IN
Packaged Width	7.94 IN
Packaged Height	10.88 IN
Country of Origin	United States of America
