• Capacitor start designs rated for 115/230VAC 60 HZ input
• Rugged die cast aluminum gear housing for maximum gear and bearing support
• Precision machined gearing, hardened for maximum load capability
• All gearing designed and rated to AGMA class 9 standards, and to withstand momentary shock overload of 200%
• Oversized output bearings for greater overhung load capacity and long life
• High carbon alloy output shaft provides maximum strength and rigidity
• All needle bearing journals are precision ground after heat treating to provide maximum fit and finish
• Heavy duty industrial oil seals keep lubricant in and dirt out
• Gears and bearings are splash lubricated with permanent, heavy duty gear oil
• Conduit box included as standard

Nameplate Specifications

Phase	1
Output HP	0.50 Hp
Output KW	0.37 kW
Voltage	115/208-230 V
Speed	41 rpm
Service Factor	1.15
Frame	48Y
Enclosure	Totally Enclosed Fan Cooled
Thermal Protection	No Protection
Ambient Temperature	40 °C
Frequency	60 Hz
Current	8.8/4.4 A
Duty	Continuous
Insulation Class	F
KVA Code	K
Drive End Bearing Size	6203
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	N

Technical Specifications

Rotation	Reversible
Mounting	Special
Shaft Type	Parallel
Overall Length	14.17 in
Frame Length	6.25 in
Shaft Diameter	0.750 in
Shaft Extension	1.5 in
Torque	700 LB-IN

General Specifications

UPC	691720006450
Weight	33.00 LB
Packaged Length	19.50 IN
Packaged Width	10.44 IN
Packaged Height	10.88 IN
Country of Origin	United States of America
