• Rugged die cast aluminum gear housing supplies maximum gear and bearing support.
• Heavy duty industrial oil seals keep lubricant in and dirt out.
• All gearing designed and rated to AGMA Class 9 Standards, and to withstand momentary shock overload of 200%.
• Capacitor start designs rated for 115/230 VAC 60 HZ input.

Nameplate Specifications

Phase	1
Output HP	0.33 Hp
Output KW	0.25 kW
Speed	288 rpm
Service Factor	1.15
Frame	48Y
Enclosure	Totally Enclosed Fan Cooled
Thermal Protection	No Protection
Ambient Temperature	40 °C
Frequency	60 Hz
Current	6.2/3.1 A
Duty	Continuous
Insulation Class	B
KVA Code	L
Drive End Bearing Size	6203
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	N

Technical Specifications

Rotation	Reversible
Mounting	Special
Shaft Type	Parallel
Overall Length	13.67 in
Frame Length	5.75 in
Shaft Diameter	0.750 in
Shaft Extension	1.5 in
Torque	70 LB-IN

General Specifications

UPC	691720006351
Weight	29.00 LB
Packaged Length	19.50 IN
Packaged Width	10.44 IN
Packaged Height	10.88 IN
Country of Origin	United States of America
