• Instant “plug-reversing” with simple three-wire connection
• Manual overload protected
• Approx. 150% starting torque - not suitable for hard start applications

Nameplate Specifications

Phase	1
Output HP	0.50 Hp
Output KW	0.37 kW
Voltage	115 V
Speed	1625 rpm
Service Factor	1.0
Frame	S56C
Enclosure	Drip Proof
Thermal Protection	Manual
Efficiency	57.5 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	6.1 A
Power Factor	98
Duty	Continuous
Insulation Class	F
Design Code	N
KVA Code	C
Drive End Bearing Size	6203
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	N
IP Code	22
Number of Speeds	1

Technical Specifications

Electrical Type	Permanent Split Capacitor
Starting Method	Across The Line
Poles	4
Rotation	Selective Counterclockwise
Resistance Main	1.53 Ohms
Mounting	Round
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	T
Overall Length	10.49 in
Frame Length	6.50 in
Shaft Diameter	0.625 in
Shaft Extension	1.87 in
Assembly/Box Mounting	F1 ONLY

General Specifications

UPC	691720105788
Weight	25.00 LB
Packaged Length	13.75 IN
Packaged Width	7.88 IN
Packaged Height	8.75 IN
Country of Origin	Mexico
