• UL recognized component listing and CSA certification ensures the product is safe for use.
• Double shielded ball bearings provide longer service life.
• Continuous or continuous air over duty design allows consistent operation at the rated power(as noted).
• Various mounting configurations (as noted).
• LEESON® motors. Motors and solutions at our core™

Nameplate Specifications

Phase	1
Output HP	0.50 Hp
Output KW	0.37 kW
Voltage	115 V
Speed	1725 rpm
Service Factor	1.35
Frame	48
Enclosure	Drip Proof
Thermal Protection	Automatic
Efficiency	76 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	4.6 A
Power Factor	96
Duty	Continuous
Insulation Class	B
Design Code	N
KVA Code	F
Drive End Bearing Size	6203
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	N
IP Code	22
Number of Speeds	1

Technical Specifications

Electrical Type	Capacitor Start Capacitor Run
Starting Method	Across The Line
Poles	4
Rotation	Selective Counterclockwise
Resistance Main	1.265 Ohms
Mounting	Resilient Base
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	NEMA 48
Overall Length	11.39 in
Frame Length	7.00 in
Shaft Diameter	0.500 in
Shaft Extension	1.5 in
Assembly/Box Mounting	F1 ONLY

General Specifications

UPC	691720005743
Weight	23.00 LB
Packaged Length	16.12 IN
Packaged Width	10.25 IN
Packaged Height	9.12 IN
Country of Origin	Mexico
