• UL and CSA Listed, Meeting NEMA MG1 standards.
• Brush holder design provides easy access for motor maintenance.
• Permanent magnet design ensures higher motor efficiency.
• Permanently lubricated sealed bearings extend the lifetime of the motor.
• Compatible with PWM or SCR type controllers.
• LEESON® motors. Motors and solutions at our core™

Nameplate Specifications

Output HP	0.50 Hp
Output KW	0.37 kW
Voltage	90 V
Speed	1750 rpm
Service Factor	1
Frame	NSS56C
Enclosure	Totally Enclosed Fan Cooled
Thermal Protection	No Protection
Efficiency	81.4 %
Ambient Temperature	40 °C
Current	5.0 A
Duty	Continuous
Insulation Class	F
Drive End Bearing Size	6203
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	N

Technical Specifications

Rotation	Reversible
Mounting	Round
Overall Length	11.81 in
Frame Length	7.50 in
Shaft Diameter	0.625 in
Shaft Extension	2.06 in
Torque	18 LB-IN

General Specifications

UPC	691720347287
Weight	25.00 LB
Packaged Length	14.44 IN
Packaged Width	10.44 IN
Packaged Height	10.88 IN
Country of Origin	United States of America
