• Designed with the exclusive Inverter Rated Insulation System (IRIS)
• Provides superior protection against voltage spikes induced by variable frequency drives
• Double shielded motor ball bearings
• Needle bearings in the parallel shaft gearboxes
• Steel conduit box provided as Standard
• Finished in high gloss hardened black enamel paint

Nameplate Specifications

Phase	3
Output HP	0.17 Hp
Output KW	0.12 kW
Voltage	208-230/460 V
Speed	9 rpm
Service Factor	1
Frame	42Y
Enclosure	Totally Enclosed Fan Cooled
Thermal Protection	No Protection
Ambient Temperature	40 °C
Frequency	60 Hz
Current	1.0/0.50 A
Power Factor	55
Duty	Continuous
Insulation Class	F
KVA Code	N
Drive End Bearing Size	6203
Opp Drive End Bearing Size	6201
UL	Recognized
CSA	Y
CE	N

Technical Specifications

Rotation	Reversible
Mounting	Special
Shaft Type	Parallel
Overall Length	13.07 in
Frame Length	6.00 in
Shaft Diameter	0.750 in
Shaft Extension	1.625 in
Torque	341 LB-IN

General Specifications

UPC	691720346457
Weight	19.20 LB
Packaged Length	19.50 IN
Packaged Width	10.44 IN
Packaged Height	10.88 IN
Country of Origin	United States of America
