• All rated for 60/50 Hz operation except hi-torque single-phase which are 60 Hz only
• Rugged die cast aluminum gear housing for maximum gear and bearing support
• Precision machined gearing, hardened for maximum load capability
• All gearing designed and rated to AGMA class 9 standards, and to withstand momentary shock overload of 200%
• Oversized output bearings for greater overhung load capacity and long life
• High carbon alloy output shaft provides maximum strength and rigidity
• All needle bearing journals are precision ground after heat treating to provide maximum fit and finish
• Heavy duty industrial oil seals keep lubricant in and dirt out; Gears and bearings are splash lubricated with permanent, heavy duty gear oil; Run capacitor supplied at no additional cost for single phase designs
• Three phase and hi-torque single phase models include conduit box, other single phase models do not; These gearmotors are designed for mounting at any angle, but motor below the reducer should be avoided to prevent leakage of lubricant into the motor should the motor shaft seal fail
• Overhung load capacities shown are at center of output shaft; Optional conduit box available

Nameplate Specifications

Phase	1
Output HP	0.33 Hp
Output KW	0.25 kW
Voltage	115/230 V
Speed	345 rpm
Service Factor	1
Frame	42Y
Enclosure	Totally Enclosed Fan Cooled
Thermal Protection	No Protection
Ambient Temperature	40 °C
Frequency	60 Hz
Current	7.2/3.6 A
Duty	Continuous
Insulation Class	F
Design Code	N
KVA Code	M
Drive End Bearing Size	6203
Opp Drive End Bearing Size	6201
UL	Recognized
CSA	Y
CE	N

Technical Specifications

Rotation	Reversible
Mounting	Special
Shaft Type	Parallel
Overall Length	14.57 in
Frame Length	7.50 in
Shaft Diameter	0.750 in
Shaft Extension	1.625 in
Torque	55 LB-IN

General Specifications

UPC	691720255346
Weight	30.00 LB
Packaged Length	19.50 IN
Packaged Width	10.44 IN
Packaged Height	10.88 IN
Country of Origin	United States of America
