• Durable rolled steel construction
• NEMA ® Desing B performance
• Meets or exceed NEMA service factors
• Double shielded ball bearings
• Continuous duty
• UL recognized component listing and CSA certified

Nameplate Specifications

Phase	1
Output HP	0.17 Hp
Output KW	0.13 kW
Voltage	115/208-230 V
Speed	3450 rpm
Service Factor	1
Frame	42
Enclosure	Totally Enclosed Non Ventilated
Thermal Protection	No Protection
Efficiency	60 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	2.5/1.3 A
Power Factor	72
Duty	Continuous
Insulation Class	B
Design Code	NO DESIGN CODE
KVA Code	N
Drive End Bearing Size	6203
Opp Drive End Bearing Size	6203
UL	Recognized
CSA	Y
CE	N
IP Code	43
Number of Speeds	1

Technical Specifications

Electrical Type	Capacitor Start Induction Run
Starting Method	Across The Line
Poles	2
Rotation	Selective Counterclockwise
Resistance Main	0 Ohms
Mounting	Rigid Base
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	STANDARD 42
Overall Length	9.56 in
Frame Length	6.50 in
Shaft Diameter	0.375 in
Shaft Extension	1.12 in
Assembly/Box Mounting	F1 ONLY

General Specifications

UPC	691720000663
Weight	19.00 LB
Packaged Length	14.44 IN
Packaged Width	7.94 IN
Packaged Height	10.88 IN
Country of Origin	United States of America
