• Large bore capacity with o-ring seal design. The most economical gear coupling design.
• Curved face teeth (sizes 1 through 7) for up to 1.5 degrees static misalignment capability.
• Series H coupling sleeves will bolt to all competitor couplings sizes 1 through 7 for interchangeability in flex halves.
• Precision-drilled flange bolt holes with special body-fitting, grade 5 bolts for a long-lasting piloted flange connection.

Technical Specifications

Max Bore w/standard key	8.625 in
Component Type	Flex Hub
Material	Carbon Steel
Coupling Size	6
Length Through Bore (in)	7.4063 in
Size Code	6
Outside Diameter (in)	18 in
Model	Series H
Length Through Bore (mm)	188.11875 mm
Coupling Type	Gear Coupling
Lube/Non-Lube	Lubricated
Measurement System	Imperial
Sleeve Outside Diameter (in)	18 in
Hub Diameter (in)	11.5 in
Bore Type	Rough Bore
Speed Max (rpm)	3,600 rpm
Torque Rating (in-lb)	759,000 in/lbs
Tooth Profile	Crowned
Configuration	Full Flex
Bore Size Max (in)	8.88 in

General Specifications

UPC	662384460940
Weight	184.00 LB
Packaged Length	14.08 IN
Packaged Width	14.08 IN
Packaged Height	14.08 IN
HTC	8483.90.8010
