• Large bore capacity with o-ring seal design. The most economical gear coupling design.
• Curved face teeth (sizes 1 through 7) for up to 1.5 degrees static misalignment capability.
• Series H coupling sleeves will bolt to all competitor couplings sizes 1 through 7 for interchangeability in flex halves.

Technical Specifications

Coupling Size	6
Bolt Type	Exposed
Model	Series H
Component Type	Slide Sleeve
Lube/Non-Lube	Lubricated
Coupling Type	Gear Coupling
Measurement System	Imperial
Bolt Circle	15.75 in
Sleeve Type	Slide
Speed Max (rpm)	4,300 rpm
Total Slide	4.0625
Sleeve Material	Steel
Outside Diameter (in)	18 in
Sleeve Overall Length (in)	6.65625 in
Torque Rating (in-lb)	759,000 in/lbs
Configuration	Gear Sleeve
Tooth Profile	Crowned

General Specifications

UPC	662384949162
Weight	80.95 LB
Packaged Length	18.00 IN
Packaged Width	18.00 IN
Packaged Height	18.00 IN
HTC	8483.90.8010
Country of Origin	Mexico
