• All-metal end ring seal design for maximum service life. The industry standard for over 75 years.
• Provides 300% greater lubricant capacity than o-ring style couplings.
• Greater lubricant capacity allows longer periods between scheduled lubrications and longer service life.
• Straight tooth design provides improved load distribution, lower stresses and longer life for the gear teeth.

Technical Specifications

Bolt Type	Shrouded
Model	FASTS
Component Type	Standard Sleeve
Coupling Size	5
Measurement System	Imperial
Coupling Type	Gear Coupling
Lube/Non-Lube	Lubricated
Sleeve Type	Flanged
Bolt Circle	13.1875 in
Speed Max (rpm)	3,880 rpm
Sleeve Overall Length (in)	6.03125 in
Outside Diameter (in)	15.3125 in
Sleeve Material	Steel
Torque Rating (in-lb)	441,000 in/lbs
Configuration	Gear Sleeve
Tooth Profile	Straight

General Specifications

UPC	662384105100
Weight	67.48 LB
Packaged Length	15.50 IN
Packaged Width	16.00 IN
Packaged Height	15.50 IN
HTC	8483.90.8010
Country of Origin	Mexico
