• Provides 300% greater lubricant capacity than o-ring style couplings.
• Greater lubricant capacity allows longer periods between scheduled lubrications and longer service life.
• Straight tooth design provides improved load distribution, lower stresses and longer life for the gear teeth.

Technical Specifications

Material	Carbon Steel
Length Through Bore (mm)	152.4 mm
Coupling Size	5
Max Bore w/standard key	5.5 in
Component Type	Mill Motor Hub
Outside Diameter (in)	5.5 in
Length Through Bore (in)	6 in
Model	FASTS
Size Code	5
Lube/Non-Lube	Lubricated
Coupling Type	Gear Coupling
Measurement System	Imperial
Bolt Type	Exposed/Shrouded
Series	Fast, Series H, Waldron
Includes	Mill Motor Hub

General Specifications

UPC	662384946864
Weight	86.00 LB
Packaged Length	12.08 IN
Packaged Width	12.08 IN
Packaged Height	12.08 IN
HTC	8483.90.8010
Country of Origin	Mexico
