• All-metal end ring seal design for maximum service life. The industry standard for over 75 years.
• Provides 300% greater lubricant capacity than o-ring style couplings.
• Greater lubricant capacity allows longer periods between scheduled lubrications and longer service life.
• Straight tooth design provides improved load distribution, lower stresses and longer life for the gear teeth.

Technical Specifications

Component Type	Medium Slide Sleeve
Bolt Type	Exposed
Coupling Size	4.5
Model	FASTS
Lube/Non-Lube	Lubricated
Coupling Type	Gear Coupling
Measurement System	Imperial
Bolt Circle	12 in
Outside Diameter (in)	13.625 in
Sleeve Type	Medium Slide
Sleeve Overall Length (in)	5.59375 in
Total Slide	4.015625
Sleeve Material	Steel
Speed Max (rpm)	4,300 rpm
Torque Rating (in-lb)	318,000 in/lbs
Tooth Profile	Crowned
Configuration	Gear Sleeve

General Specifications

UPC	662384997101
Weight	57.00 LB
Packaged Length	14.00 IN
Packaged Width	14.00 IN
Packaged Height	14.00 IN
HTC	8483.90.8010
