• All-metal end ring seal design for maximum service life. The industry standard for over 75 years.
• Provides 300% greater lubricant capacity than o-ring style couplings.
• Greater lubricant capacity allows longer periods between scheduled lubrications and longer service life.
• Straight tooth design provides improved load distribution, lower stresses and longer life for the gear teeth.

Technical Specifications

Component Type	Standard Sleeve
Bolt Type	Shrouded
Coupling Size	3
Model	FASTS
Measurement System	Imperial
Coupling Type	Gear Coupling
Lube/Non-Lube	Lubricated
Speed Max (rpm)	6,800 rpm
Sleeve Material	Steel
Outside Diameter (in)	9.4375 in
Sleeve Overall Length (in)	3.65625 in
Bolt Circle	8 in
Sleeve Type	Flanged
Torque Rating (in-lb)	101,000 in/lbs
Configuration	Gear Sleeve
Tooth Profile	Straight

General Specifications

UPC	662384103106
Weight	14.36 LB
Packaged Length	9.75 IN
Packaged Width	9.75 IN
Packaged Height	9.75 IN
HTC	8483.90.8010
Country of Origin	Mexico
