• Large bore capacity with o-ring seal design. The most economical gear coupling design.
• Curved face teeth (sizes 1 through 7) for up to 1.5 degrees static misalignment capability.
• Series H coupling sleeves will bolt to all competitor couplings sizes 1 through 7 for interchangeability in flex halves.
• Precision-drilled flange bolt holes with special body-fitting, grade 5 bolts for a long-lasting piloted flange connection.

Technical Specifications

Size Code	2
Length Through Bore (in)	2.4375 in
Coupling Size	2
Max Bore w/standard key	2.75 in
Length Through Bore (mm)	61.9125 mm
Outside Diameter (in)	7 in
Material	Carbon Steel
Model	Series H
Component Type	Flex Hub
Measurement System	Imperial
Coupling Type	Gear Coupling
Lube/Non-Lube	Lubricated
Bore Type	Rough Bore
Speed Max (rpm)	9,300 rpm
Sleeve Outside Diameter (in)	7 in
Hub Diameter (in)	4 in
Torque Rating (in-lb)	31,500 in/lbs
Configuration	Gear
Tooth Profile	Crowned
Bore Size Max (in)	2.88 in

General Specifications

UPC	662384402094
Weight	8.91 LB
Packaged Length	4.90 IN
Packaged Width	4.90 IN
Packaged Height	3.20 IN
HTC	8483.90.8010
