• All-metal end ring seal design for maximum service life. The industry standard for over 75 years.
• Provides 300% greater lubricant capacity than o-ring style couplings.
• Greater lubricant capacity allows longer periods between scheduled lubrications and longer service life.
• Straight tooth design provides improved load distribution, lower stresses and longer life for the gear teeth.

Technical Specifications

Bolt Type	Shrouded
Component Type	Standard Sleeve
Model	FASTS
Coupling Size	2
Lube/Non-Lube	Lubricated
Measurement System	Imperial
Coupling Type	Gear Coupling
Sleeve Material	Steel
Bolt Circle	5.8125 in
Speed Max (rpm)	9,300 rpm
Sleeve Overall Length (in)	2.46875 in
Sleeve Type	Flanged
Outside Diameter (in)	7 in
Torque Rating (in-lb)	31,500 in/lbs
Configuration	Gear Sleeve
Tooth Profile	Straight

General Specifications

UPC	662384102109
Weight	7.06 LB
Packaged Length	7.80 IN
Packaged Width	7.10 IN
Packaged Height	4.50 IN
HTC	8483.90.8010
Country of Origin	Mexico
