• Spacer coupling with economical 3-component design.
• Unitized Disc Packs for ease of maintenance, replaceable without moving the connected equipment.
• HT (High Torque) disc packs for medium and heavy duty applications.
• Meet AGMA Class 9 balance off the shelf. Balance to AGMA 10, or compliance with API610 are available options.

Technical Specifications

Style	KD21
Stock C Dimension	7
Configuration	2 standard hubs
Total Length (Std Hub Post) (in)	11.76 in
Hub Material	Carbon Steel
Axial Capacity (+/-)	0.11
Coupling Size	204
Total WR2 (lb-in2)	160 psi
Bore Type	Finished Bore
Torque [Max] (ft-lb)	6,000 ft/lbs
Torque Rating (in-lb)	36,000 in/lbs
Length Through Bore standard hub (in)	2.38 in
Bore Size Min (in)	1 in

General Specifications

UPC	662384153316
Weight	40.00 LB
