• Reversible Standard hub to accommodate various shaft separations of a close coupled disc coupling.
• Meet AGMA Class 8 balance off the shelf, and may be component balanced to AGMA Class 9.

Technical Specifications

Style	KD10
Hub Material	Carbon Steel
Bore Type	Rough Bore
Coupling Size	204
Length Through Bore (in)	2.75 in
Component Type	Standard Hub
Overall Length (in)	2.75 in
Bore Size Max (in)	2.62 in
Bore Size Min (in)	1 in

General Specifications

UPC	662384141269
Weight	9.94 LB
Packaged Length	7.40 IN
Packaged Width	7.10 IN
Packaged Height	4.80 IN
HTC	8483.90.8010
Country of Origin	Mexico
