• Unique 40 degree tooth form distributes loads over a larger area than a 20 degree tooth.
• Curved face teeth (sizes 1 through 7) for up to 1.5 degrees static misalignment capability.
• Unique, high misalignment seal design - superior to standard o-rings.
• Optional pilot rings provide a positive piloted connection between sleeves and/or rigids.

Technical Specifications

Coupling Size	1.5
Component Type	Spacer
Model	Waldron
Bolt Type	Shrouded
Measurement System	Imperial
Coupling Type	Gear Coupling
Lube/Non-Lube	Lubricated
Outside Diameter (in)	6 in
Series	Fast, Series H, Waldron
Includes	Spacer
Material	Carbon Steel

General Specifications

UPC	662384107364
Weight	5.61 LB
Packaged Length	6.30 IN
Packaged Width	6.40 IN
Packaged Height	4.50 IN
HTC	8483.90.8010
Country of Origin	Mexico
