• Special convoluted disc design to reduce disc stresses and restoring forces.
• Discs made of high - grade stainless steel (AISI-301), ensuring high strength, high endurance to fatigue and resistance to most environmental conditions. Possibility to supply coated discs.
• Unitized disc packs and  designed with special metric high grade bolts and nuts with incorporated washers. Reduced tightening torque JS nuts available for large sizes and high bolt torques.

Technical Specifications

Style	Lamidisc™
Angular Misalignment, ±ΔKw (2) - deg	0.33 °
Coupling Size	380
Torque Rating (N⋅m)	42,300 N·m
Number of Bolt Holes	6
Disc Shape	Scalloped
Component Type	Disc Pack Assembly

General Specifications

UPC	662384000092
Weight	23.44 LB
Packaged Length	14.50 IN
Packaged Width	14.50 IN
Packaged Height	1.80 IN
HTC	8483.90.8010
Country of Origin	Spain
