• Increased pitch gear diameter allows for larger maximum bore and higher torque capacity than other equivalent size couplings.
• MT coupling halves (AGMA sizes 1-7) are interchangeable with couplings of other manufacturers. MTT type are not interchangeable.
• Coupling halves are joined by special body fitting grade 8 bolts. Adapted nuts are used. While applying tightening torque, nuts rotate and bolts are kept fixed.

Technical Specifications

Overall Length (mm)	69.5 mm
Coupling Size	98
Style	MT
Coupling Type	Gear Coupling
Outside Diameter (mm)	156 mm
Tooth Profile	Crown faced, Involute Stub Tooth
Outside Diameter (in)	6.14173228346457 in
Configuration	Sleeve Only
Material	Alloy Steel
Overall Length (in)	2.73622047244094 in
Measurement System	Metric
Lube/Non-Lube	Lubricated

General Specifications

UPC	662384000849
Weight	8.82 LB
Packaged Length	8.27 IN
Packaged Width	8.27 IN
Packaged Height	2.74 IN
Country of Origin	Slovakia
