• Increased pitch gear diameter allows for larger maximum bore and higher torque capacity than other equivalent size couplings.
• MT coupling halves (AGMA sizes 1-7) are interchangeable with couplings of other manufacturers. MTT type are not interchangeable.
• Coupling halves are joined by special body fitting grade 8 bolts. Adapted nuts are used. While applying tightening torque, nuts rotate and bolts are kept fixed.

Technical Specifications

Tooth Profile	Crown faced, Involute Stub Tooth
Overall Length (in)	5.61023622047244 in
Configuration	Sleeve Only
Outside Diameter (mm)	308.5 mm
Style	MT
Coupling Type	Gear Coupling
Coupling Size	190
Material	Alloy Steel
Outside Diameter (in)	12.1456692913386 in
Overall Length (mm)	142.5 mm
Lube/Non-Lube	Lubricated
Measurement System	Metric

General Specifications

UPC	662384000894
Weight	59.51 LB
Packaged Length	14.96 IN
Packaged Width	14.96 IN
Packaged Height	5.61 IN
Country of Origin	China
