• Increased pitch gear diameter allows for larger maximum bore and higher torque capacity than other equivalent size couplings.
• MT coupling halves (AGMA sizes 1-7) are interchangeable with couplings of other manufacturers. MTT type are not interchangeable.
• Coupling halves are joined by special body fitting grade 8 bolts. Adapted nuts are used. While applying tightening torque, nuts rotate and bolts are kept fixed.

Technical Specifications

Material	Alloy Steel
Coupling Type	Gear Coupling
Tooth Profile	Crown faced, Involute Stub Tooth
Outside Diameter (mm)	210.5 mm
Style	MT
Coupling Size	132
Configuration	Sleeve Only
Outside Diameter (in)	8.28740157480315 in
Overall Length (mm)	96 mm
Overall Length (in)	3.77952755905512 in
Measurement System	Metric
Lube/Non-Lube	Lubricated

General Specifications

UPC	662384000863
Weight	23.14 LB
Packaged Length	10.79 IN
Packaged Width	10.79 IN
Packaged Height	3.78 IN
Country of Origin	Slovakia
