• 90% Efficiency-Up to 2x Torque
• Four sizes can replace up to twelve sizes of worm speed reducers
• Machine Polished 316 stainless steel housing
• Rolling action gearing (helical and hypoid)
• Over-sized bearings
• Viton® seals
• Bronze bushing quill liner
• Factory lubricated with Food Grade synthetic lubricant - USDA H1
• HubLoc® keyless bushing system is available on hollow output bore SSHERA gear drives.

Technical Specifications

Input HP	1.53
Product Line	HERA
Ratio	52.50:1
Product Type	RIGHT ANGLE
Series Code	HERA45
Output RPM	33.3
Style	EK
Input Diameter (in)	0.876 in
Service Factor	1
Input HP @ 1750 RPM	1.53
Input Style	C-Face Quill
Certifications	IP69K, USDA Accepted Equipment
Mounting Type	EK
Housing Length (in)	8.02 in
Housing Height (in)	7.14 in
Housing Width (in)	6.75 in
Reduction	Double
Length Through Bore (in)	6.75 in
Motor Frame Size	140TC
Housing Material	Stainless Steel
Output Torque Range (in-lb)	2500 to 5000 in lbs in/lbs
Housing Dimensions (in)	(L)8.02 x (H)7.14 x (W)6.75 in
Center Distance (in)	3.263 in
Output Shaft	Hollow Bore
Nominal Ratio	50:1
Output Torque Rating (in-lb)	2600 in/lbs
Gear Drive SIze	SSHERA45

General Specifications

UPC	662961039064
Weight	50.00 LB
Packaged Length	14.00 IN
Packaged Width	12.25 IN
Packaged Height	13.50 IN
