• Rugged cast iron housing
• Universal Mounting Dimensions
• Spiral Bevel (SP) or Straight Bevel (ST) gearing
• Alloy shafting
• Heavy-duty industrial seals

Technical Specifications

Series Code	M3
Input Diameter (in)	0.625 in
Gear Type	Straight Bevel
Style	C,F
Output RPM	1750
Output Diameter (in)	0.625 in
Product Line	Bevel Gear Drives
Product Type	Right Angle
Input HP	2.25
Maximum Input HP	2.25 @ 1750 RPM
Ratio	1:1
Service Factor	1
Ratio Range	1:1
Input Style	Shaft
Housing Dimensions	(L)4.65625 x (H)3.1875 x (W)3.46875
Housing Height (in)	3.1875 in
Reduction	Single
Housing Length (in)	4.65625 in
Housing Width (in)	3.46875 in
Output Shaft Direction	L or R
Output Shaft	Shaft
Output Torque Rating (in-lb)	81 in/lbs
Housing Material	Cast Iron
Gear Drive Size	M3
Output Torque Range (in-lb)	< 250 in lbs in/lbs

General Specifications

UPC	662798010847
Weight	5.80 LB
Packaged Length	9.00 IN
Packaged Width	9.00 IN
Packaged Height	4.00 IN
HTC	8483.40.5050
Country of Origin	United States of America
