• Rugged cast iron housing
• Universal Mounting Dimensions
• Spiral Bevel (SP) or Straight Bevel (ST) gearing
• Alloy shafting
• Heavy-duty industrial seals

Technical Specifications

Input Diameter (in)	0.625 in
Output RPM	1750
Ratio	1:1
Maximum Input HP	2.25 @ 1750 RPM
Output Diameter (in)	0.625 in
Input HP	2.25
Series Code	M2
Style	G
Gear Type	Straight Bevel
Product Type	Right Angle
Product Line	Bevel Gear Drives
Service Factor	1
Ratio Range	1:1
Input Style	Shaft
Housing Width (in)	4.131 in
Housing Length (in)	4.796875 in
Reduction	Single
Housing Dimensions	(L)4.796875 x (H)3.1875 x (W)4.131
Housing Height (in)	3.1875 in
Output Shaft Direction	Double
Output Shaft	Shaft
Housing Material	Cast Iron
Output Torque Rating (in-lb)	81 in/lbs
Output Torque Range (in-lb)	< 250 in lbs in/lbs
Gear Drive Size	M2

General Specifications

UPC	662798003894
Weight	10.00 LB
Packaged Length	9.00 IN
Packaged Width	9.00 IN
Packaged Height	4.00 IN
HTC	8483.40.5050
Country of Origin	United States of America
