• Rugged cast iron housing
• Universal Mounting Dimensions
• Spiral Bevel (SP) or Straight Bevel (ST) gearing
• Alloy shafting
• Heavy-duty industrial seals

Technical Specifications

Input Diameter (in)	0.625 in
Input HP	2.25
Output RPM	1750
Ratio	1:1
Product Type	Right Angle
Product Line	Bevel Gear Drives
Output Diameter (in)	0.625 in
Style	D,E
Maximum Input HP	2.25 @ 1750 RPM
Service Factor	1
Gear Type	Straight Bevel
Series Code	M2
Ratio Range	1:1
Input Style	Shaft
Housing Length (in)	4.796875 in
Housing Width (in)	4.131 in
Housing Height (in)	3.1875 in
Housing Dimensions	(L)4.796875 x (H)3.1875 x (W)4.131
Reduction	Single
Output Shaft Direction	L or R
Output Torque Range (in-lb)	< 250 in lbs in/lbs
Gear Drive Size	M2
Output Torque Rating (in-lb)	81 in/lbs
Output Shaft	Shaft
Housing Material	Cast Iron

General Specifications

UPC	662798003795
Weight	7.40 LB
Packaged Length	9.00 IN
Packaged Width	9.00 IN
Packaged Height	4.00 IN
HTC	8483.40.5050
Country of Origin	United States of America
