• 90% Efficiency-Up to 2x Torque
• Four sizes can replace up to twelve sizes of worm speed reducers
• Cast iron housing
• Rolling action gearing (helical and hypoid)
• Over-sized bearings
• Viton® seals
• Bronze bushing quill liner
• Factory lubricated with Food Grade synthetic lubricant - USDA H1
• HubLoc® keyless bushing system is available on hollow output bore HERA gear drives.

Technical Specifications

Input HP	8.5
Input Diameter (in)	1.126 in
Ratio	7.80:1
Series Code	HERA45
Output Diameter (in)	1.125 in
Service Factor	1
Product Line	HERA
Output RPM	224.4
Product Type	RIGHT ANGLE
Style	ES
Input HP @ 1750 RPM	8.5
Input Style	C-Face Quill
Housing Length (in)	8 in
Housing Height (in)	6.938 in
Mounting Type	ES
Housing Width (in)	6.25 in
Reduction	Double
Length Through Bore (in)	6.25 in
Motor Frame Size	180TC
Gear Drive SIze	HERA45
Output Shaft	Hollow Bore
Center Distance (in)	3.263 in
Nominal Ratio	7.5:1
Output Torque Rating (in-lb)	2149 in/lbs
Output Torque Range (in-lb)	1000 to 2500 in lbs in/lbs
Housing Dimensions (in)	(L)8 x (H)6.938 x (W)6.25 in
Housing Material	Cast iron

General Specifications

UPC	662798734118
Weight	42.00 LB
Packaged Length	14.00 IN
Packaged Width	12.25 IN
Packaged Height	13.50 IN
