• 90% Efficiency-Up to 2x Torque
• Four sizes can replace up to twelve sizes of worm speed reducers
• Cast iron housing
• Rolling action gearing (helical and hypoid)
• Over-sized bearings
• Viton® seals
• Bronze bushing quill liner
• Factory lubricated with Food Grade synthetic lubricant - USDA H1
• HubLoc® keyless bushing system is available on hollow output bore HERA gear drives.

Technical Specifications

Ratio	7.80:1
Output Diameter (in)	1.000 in
Output RPM	224.4
Series Code	HERA45
Style	ES
Product Line	HERA
Input HP	8.5
Input Diameter (in)	1.126 in
Product Type	RIGHT ANGLE
Service Factor	1
Input Style	C-Face Quill
Input HP @ 1750 RPM	8.5
Mounting Type	ES
Housing Length (in)	8 in
Housing Width (in)	6.25 in
Housing Height (in)	6.938 in
Reduction	Double
Length Through Bore (in)	6.25 in
Motor Frame Size	180TC
Center Distance (in)	3.263 in
Output Torque Range (in-lb)	1000 to 2500 in lbs in/lbs
Nominal Ratio	7.5:1
Housing Dimensions (in)	(L)8 x (H)6.938 x (W)6.25 in
Output Shaft	Hollow Bore
Gear Drive SIze	HERA45
Housing Material	Cast iron
Output Torque Rating (in-lb)	2149 in/lbs

General Specifications

UPC	662798734033
Weight	42.00 LB
Packaged Length	14.00 IN
Packaged Width	12.25 IN
Packaged Height	13.50 IN
