• 90% Efficiency-Up to 2x Torque
• Four sizes can replace up to twelve sizes of worm speed reducers
• Cast iron housing
• Rolling action gearing (helical and hypoid)
• Over-sized bearings
• Viton® seals
• Bronze bushing quill liner
• Factory lubricated with Food Grade synthetic lubricant - USDA H1
• HubLoc® keyless bushing system is available on hollow output bore HERA gear drives.

Technical Specifications

Output RPM	112.2
Product Type	RIGHT ANGLE
Series Code	HERA45
Product Line	HERA
Input HP	5.14
Ratio	15.60:1
Output Diameter (in)	1.500 in
Style	ES
Service Factor	1
Input Diameter (in)	0.626 in
Input HP @ 1750 RPM	5.14
Input Style	C-Face Quill
Reduction	Double
Housing Width (in)	6.25 in
Housing Height (in)	6.938 in
Mounting Type	ES
Housing Length (in)	8 in
Length Through Bore (in)	6.25 in
Motor Frame Size	56C
Nominal Ratio	15:1
Output Torque Range (in-lb)	2500 to 5000 in lbs in/lbs
Output Torque Rating (in-lb)	2600 in/lbs
Gear Drive SIze	HERA45
Output Shaft	Hollow Bore
Housing Material	Cast iron
Center Distance (in)	3.263 in
Housing Dimensions (in)	(L)8 x (H)6.938 x (W)6.25 in

General Specifications

UPC	662798733487
Weight	42.00 LB
Packaged Length	14.00 IN
Packaged Width	12.25 IN
Packaged Height	13.50 IN
