• 90% Efficiency-Up to 2x Torque
• Four sizes can replace up to twelve sizes of worm speed reducers
• Cast iron housing
• Rolling action gearing (helical and hypoid)
• Over-sized bearings
• Viton® seals
• Bronze bushing quill liner
• Factory lubricated with Food Grade synthetic lubricant - USDA H1
• HubLoc® keyless bushing system is available on hollow output bore HERA gear drives.

Technical Specifications

Product Type	RIGHT ANGLE
Product Line	HERA
Output RPM	33.3
Ratio	52.50:1
Input HP	0.65
Input Diameter (in)	0.876 in
Output Diameter (in)	1.438 in
Series Code	HERA35
Service Factor	1
Style	ES
Input Style	C-Face Quill
Input HP @ 1750 RPM	0.65
Housing Height (in)	5.75 in
Mounting Type	ES
Reduction	Double
Housing Length (in)	7.19 in
Housing Width (in)	5.5 in
Length Through Bore (in)	5.5 in
Motor Frame Size	140TC
Gear Drive SIze	HERA35
Housing Material	Cast iron
Output Torque Rating (in-lb)	1100 in/lbs
Output Shaft	Hollow Bore
Output Torque Range (in-lb)	1000 to 2500 in lbs in/lbs
Housing Dimensions (in)	(L)7.19 x (H)5.75 x (W)5.5 in
Nominal Ratio	50:1
Center Distance (in)	2.509 in

General Specifications

UPC	662798806372
Weight	31.00 LB
Packaged Length	12.00 IN
Packaged Width	10.00 IN
Packaged Height	11.00 IN
