• Cast aluminum housing
• Universal mounting (4 surfaces)
• Factory lubricated
• Spiral bevel gearing
• Corrosion resistant shafting

Technical Specifications

Product Line	Bevel Gear Drives
Style	D,E
Service Factor	1
Product Type	Right Angle
Input Diameter (in)	0.6245 in
Output RPM	875
Series Code	AD5
Gear Type	Spiral Bevel
Maximum Input HP	1.07 @ 1750 RPM
Output Diameter (in)	0.625 in
Ratio	2:1
Input Style	Shaft
Ratio Range	2:1
Housing Height (in)	2.005 in
Housing Dimensions	(L)4.44 x (H)2.005 x (W)4.25
Housing Width (in)	4.25 in
Reduction	Single
Housing Length (in)	4.44 in
Output Shaft Direction	L or R
Output Torque Range (in-lb)	< 250 in lbs in/lbs
Housing Material	Aluminum
Output Shaft	Shaft
Output Torque Rating (in-lb)	77.2 in/lbs
Gear Drive Size	AD5

General Specifications

UPC	662798008424
Weight	2.00 LB
Packaged Length	9.00 IN
Packaged Width	9.00 IN
Packaged Height	4.00 IN
HTC	8483.40.5050
Country of Origin	United States of America
