• Cast aluminum housing
• Universal mounting (4 surfaces)
• Factory lubricated
• Spiral bevel gearing
• Corrosion resistant shafting

Technical Specifications

Style	C,F
Series Code	AD5
Maximum Input HP	2.19 @ 1750 RPM
Input Diameter (in)	0.6245 in
Output Diameter (in)	0.625 in
Gear Type	Spiral Bevel
Ratio	1:1
Product Line	Bevel Gear Drives
Output RPM	1750
Product Type	Right Angle
Service Factor	1
Ratio Range	1:1
Input Style	Shaft
Housing Length (in)	4.44 in
Housing Width (in)	4.25 in
Housing Dimensions	(L)4.44 x (H)2.005 x (W)4.25
Reduction	Single
Housing Height (in)	2.005 in
Output Shaft Direction	L or R
Output Torque Range (in-lb)	< 250 in lbs in/lbs
Output Torque Rating (in-lb)	78.7 in/lbs
Housing Material	Aluminum
Output Shaft	Shaft
Gear Drive Size	AD5

General Specifications

UPC	662798008400
Weight	2.80 LB
Packaged Length	9.00 IN
Packaged Width	9.00 IN
Packaged Height	4.00 IN
HTC	8483.40.5050
Country of Origin	United States of America
