• Cast aluminum housing
• Universal mounting (4 surfaces)
• Factory lubricated
• Spiral bevel gearing
• Corrosion resistant shafting

Technical Specifications

Style	D,E
Gear Type	Spiral Bevel
Output Diameter (in)	0.750 in
Product Type	Right Angle
Input Diameter (in)	0.750 in
Service Factor	1
Output RPM	1750
Ratio	1:1
Product Line	Bevel Gear Drives
Maximum Input HP	5.27 @ 1750 RPM
Series Code	AD3
Input Style	Shaft
Ratio Range	1:1
Housing Width (in)	6 in
Reduction	Single
Housing Dimensions	(L)6.86 x (H)3.005 x (W)6
Housing Height (in)	3.005 in
Housing Length (in)	6.86 in
Output Shaft Direction	L or R
Output Torque Range (in-lb)	< 250 in lbs in/lbs
Output Torque Rating (in-lb)	189.7 in/lbs
Output Shaft	Shaft
Housing Material	Aluminum
Gear Drive Size	AD3

General Specifications

UPC	662798004044
Weight	9.00 LB
Packaged Length	9.00 IN
Packaged Width	9.00 IN
Packaged Height	4.00 IN
HTC	8483.40.5050
Country of Origin	United States of America
