• Cast aluminum housing
• Universal mounting (4 surfaces)
• Factory lubricated
• Spiral bevel gearing
• Corrosion resistant shafting

Technical Specifications

Ratio	2:1
Series Code	AD1
Product Line	Bevel Gear Drives
Style	A,B
Gear Type	Spiral Bevel
Maximum Input HP	0.262 @ 1750 RPM
Product Type	Right Angle
Service Factor	1
Output Diameter (in)	0.375 in
Output RPM	875
Input Diameter (in)	0.3745 in
Input Style	Shaft
Ratio Range	2:1
Housing Dimensions	(L)3.015 x (H)1.255 x (W)1.78125
Housing Length (in)	3.015 in
Housing Width (in)	1.78125 in
Housing Height (in)	1.255 in
Reduction	Single
Output Shaft Direction	Double
Housing Material	Aluminum
Output Torque Range (in-lb)	< 250 in lbs in/lbs
Output Torque Rating (in-lb)	18.9 in/lbs
Gear Drive Size	AD1
Output Shaft	Shaft

General Specifications

UPC	662798003931
Weight	1.00 LB
Packaged Length	9.00 IN
Packaged Width	9.00 IN
Packaged Height	4.00 IN
HTC	8483.40.5050
Country of Origin	United States of America
