• Rugged cast iron housing
• Universal Mounting Dimensions
• Spiral Bevel (SP) or Straight Bevel (ST) gearing
• Alloy shafting
• Heavy-duty industrial seals

Technical Specifications

Input HP	44
Style	C,F
Service Factor	1
Output Diameter (in)	1.375 in
Product Type	Right Angle
Gear Type	Straight Bevel
Output RPM	850
Series Code	88
Input Diameter (in)	1.375 in
Ratio	1:1
Maximum Input HP	44 @ 850 RPM
Product Line	Bevel Gear Drives
Input Style	Shaft
Ratio Range	1:1
Housing Height (in)	8.1875 in
Reduction	Single
Housing Width (in)	9.8125 in
Housing Length (in)	11.65625 in
Housing Dimensions	(L)11.65625 x (H)8.1875 x (W)9.8125
Output Shaft Direction	L or R
Output Torque Rating (in-lb)	3260 in/lbs
Output Torque Range (in-lb)	2500 to 5000 in lbs in/lbs
Housing Material	Cast Iron
Output Shaft	Shaft
Gear Drive Size	88

General Specifications

UPC	662798007045
Weight	85.00 LB
Packaged Length	16.25 IN
Packaged Width	15.50 IN
Packaged Height	11.00 IN
HTC	8483.40.5050
Country of Origin	United States of America
