• Rugged cast iron housing
• Universal Mounting Dimensions
• Spiral Bevel (SP) or Straight Bevel (ST) gearing
• Alloy shafting
• Heavy-duty industrial seals

Technical Specifications

Product Line	Bevel Gear Drives
Output Diameter (in)	1.375 in
Series Code	88
Style	A,B
Input HP	44
Output RPM	850
Product Type	Right Angle
Gear Type	Straight Bevel
Input Diameter (in)	1.375 in
Ratio	1:1
Service Factor	1
Input Style	Shaft
Ratio Range	1:1
Housing Width (in)	9.8125 in
Housing Dimensions	(L)11.65625 x (H)8.1875 x (W)9.8125
Housing Length (in)	11.65625 in
Housing Height (in)	8.1875 in
Reduction	Single
Output Shaft Direction	Double
Output Torque Rating (in-lb)	3,260 in/lbs
Output Shaft	Shaft
Housing Material	Cast Iron
Output Torque Range (in-lb)	2500 to 5000 in lbs in/lbs
Gear Drive Size	88

General Specifications

UPC	662798007021
Weight	86.00 LB
Packaged Length	16.25 IN
Packaged Width	15.50 IN
Packaged Height	11.00 IN
HTC	8483.40.5050
Country of Origin	United States of America
