• Rugged ductile iron housing
• Universal Mounting Dimensions
• Spiral Bevel (SP) or Straight Bevel (ST) gearing
• Alloy shafting
• Heavy-duty industrial seals

Technical Specifications

Series Code	800
Gear Type	Straight Bevel
Maximum Input HP	56.2 @ 690 RPM
Output Diameter (in)	1.500 in
Input Diameter (in)	1.500 in
Service Factor	1
Input HP	56.2
Style	D,E
Ratio	1:1
Output RPM	690
Product Type	Right Angle
Product Line	Bevel Gear Drives
Input Style	Shaft
Ratio Range	1:1
Housing Dimensions	(L)12.59375 x (H)8.1875 x (W)9.90625
Housing Width (in)	9.90625 in
Housing Length (in)	12.59375 in
Reduction	Single
Housing Height (in)	8.1875 in
Output Shaft Direction	L or R
Output Torque Range (in-lb)	5000 to 10000 in lbs in/lbs
Gear Drive Size	800
Output Torque Rating (in-lb)	5130 in/lbs
Output Shaft	Shaft
Housing Material	Ductile Iron

General Specifications

UPC	662798020464
Weight	94.80 LB
Packaged Length	16.25 IN
Packaged Width	15.50 IN
Packaged Height	11.00 IN
HTC	8483.40.5050
Country of Origin	United States of America
