• Rugged ductile iron housing
• Universal Mounting Dimensions
• Spiral Bevel (SP) or Straight Bevel (ST) gearing
• Alloy shafting
• Heavy-duty industrial seals

Technical Specifications

Output Diameter (in)	1.500 in
Product Type	Right Angle
Maximum Input HP	132 @ 1750 RPM
Style	A,B
Product Line	Bevel Gear Drives
Service Factor	1
Series Code	800
Output RPM	1750
Gear Type	Spiral Bevel
Input Diameter (in)	1.500 in
Ratio	1:1
Input Style	Shaft
Ratio Range	1:1
Reduction	Single
Housing Length (in)	12.59375 in
Housing Dimensions	(L)12.59375 x (H)8.1875 x (W)9.90625
Housing Height (in)	8.1875 in
Housing Width (in)	9.90625 in
Output Shaft Direction	Double
Output Torque Range (in-lb)	2500 to 5000 in lbs in/lbs
Output Torque Rating (in-lb)	4750 in/lbs
Output Shaft	Shaft
Gear Drive Size	800
Housing Material	Ductile Iron

General Specifications

UPC	662798020761
Weight	97.00 LB
Packaged Length	16.25 IN
Packaged Width	15.50 IN
Packaged Height	11.00 IN
HTC	8483.40.5050
Country of Origin	United States of America
