• Rugged cast iron housing
• Universal Mounting Dimensions
• Spiral Bevel (SP) or Straight Bevel (ST) gearing
• Alloy shafting
• Heavy-duty industrial seals

Technical Specifications

Gear Type	Spiral Bevel
Output Diameter (in)	1.000 in
Maximum Input HP	19.9
Input Diameter (in)	1.250 in
Product Line	Bevel Gear Drives
Product Type	Right Angle
Output RPM	2300
Series Code	66
Ratio	1:2
Service Factor	1
Style	C,F
Ratio Range	1:2
Input Style	Shaft
Housing Length (in)	8.6875 in
Housing Height (in)	5.625 in
Housing Dimensions	(L)8.6875 x (H)5.625 x (W)7.25
Housing Width (in)	7.25 in
Reduction	Single
Output Shaft Direction	L or R
Output Shaft	Shaft
Output Torque Rating (in-lb)	545 in/lbs
Gear Drive Size	66
Output Torque Range (in-lb)	500 to 1000 in lbs in/lbs
Housing Material	Cast Iron

General Specifications

UPC	662798006994
Weight	43.00 LB
Packaged Length	13.25 IN
Packaged Width	12.50 IN
Packaged Height	7.50 IN
