• Rugged cast iron housing
• Universal Mounting Dimensions
• Spiral Bevel (SP) or Straight Bevel (ST) gearing
• Alloy shafting
• Heavy-duty industrial seals

Technical Specifications

Product Type	Right Angle
Product Line	Bevel Gear Drives
Input Diameter (in)	1.250 in
Service Factor	1
Ratio	1:1
Output Diameter (in)	1.250 in
Maximum Input HP	24.2 @ 1150 RPM
Style	C,F
Input HP	24.2
Gear Type	Straight Bevel
Series Code	66
Output RPM	1150
Input Style	Shaft
Ratio Range	1:1
Reduction	Single
Housing Width (in)	7.25 in
Housing Length (in)	8.6875 in
Housing Height (in)	5.625 in
Housing Dimensions	(L)8.6875 x (H)5.625 x (W)7.25
Output Shaft Direction	L or R
Housing Material	Cast Iron
Output Shaft	Shaft
Output Torque Rating (in-lb)	1320 in/lbs
Output Torque Range (in-lb)	1000 to 2500 in lbs in/lbs
Gear Drive Size	66

General Specifications

UPC	662798006420
Weight	41.00 LB
Packaged Length	13.25 IN
Packaged Width	12.50 IN
Packaged Height	7.50 IN
HTC	8483.40.5050
Country of Origin	United States of America
