• Rugged cast iron housing
• Universal Mounting Dimensions
• Spiral Bevel (SP) or Straight Bevel (ST) gearing
• Alloy shafting
• Heavy-duty industrial seals

Technical Specifications

Style	A,B
Input Diameter (in)	1.250 in
Gear Type	Straight Bevel
Output Diameter (in)	1.250 in
Ratio	1:1.50
Maximum Input HP	11.8 @ 850 RPM
Product Line	Bevel Gear Drives
Series Code	66
Output RPM	1275
Service Factor	1
Product Type	Right Angle
Input HP	11.8
Input Style	Shaft
Ratio Range	1:1.5
Reduction	Single
Housing Width (in)	7.25 in
Housing Height (in)	5.625 in
Housing Length (in)	8.6875 in
Housing Dimensions	(L)8.6875 x (H)5.625 x (W)7.25
Output Shaft Direction	Double
Output Torque Range (in-lb)	500 to 1000 in lbs in/lbs
Output Shaft	Shaft
Output Torque Rating (in-lb)	580 in/lbs
Housing Material	Cast Iron
Gear Drive Size	66

General Specifications

UPC	662798006659
Weight	43.00 LB
Packaged Length	13.25 IN
Packaged Width	12.50 IN
Packaged Height	7.50 IN
HTC	8483.40.5050
Country of Origin	United States of America
