• Rugged cast iron housing
• Universal Mounting Dimensions
• Spiral Bevel (SP) or Straight Bevel (ST) gearing
• Alloy shafting
• Heavy-duty industrial seals

Technical Specifications

Series Code	600
Product Line	Bevel Gear Drives
Product Type	Right Angle
Input HP	15
Ratio	1.50:1
Service Factor	1
Gear Type	Straight Bevel
Output Diameter (in)	1.375 in
Output RPM	1166.7
Style	D,E
Input Diameter (in)	1.375 in
Ratio Range	1.5:1
Input Style	Shaft
Housing Dimensions	(L)8.71875 x (H)5.625 x (W)7.25
Housing Length (in)	8.71875 in
Housing Width (in)	7.25 in
Reduction	Single
Housing Height (in)	5.625 in
Output Shaft Direction	L or R
Output Shaft	Shaft
Output Torque Range (in-lb)	500 to 1000 in lbs in/lbs
Output Torque Rating (in-lb)	810 in/lbs
Housing Material	Cast Iron
Gear Drive Size	600

General Specifications

UPC	662798745541
Weight	48.00 LB
Packaged Length	13.25 IN
Packaged Width	12.50 IN
Packaged Height	7.50 IN
HTC	8483.40.5050
Country of Origin	United States of America
