• Rugged cast iron housing
• Universal Mounting Dimensions
• Spiral Bevel (SP) or Straight Bevel (ST) gearing
• Alloy shafting
• Heavy-duty industrial seals

Technical Specifications

Maximum Input HP	46 @ 1750 RPM
Gear Type	Spiral Bevel
Input Diameter (in)	1.375 in
Series Code	600
Output Diameter (in)	1.375 in
Product Line	Bevel Gear Drives
Output RPM	1750
Style	A,B
Product Type	Right Angle
Service Factor	1
Ratio	1:1
Input Style	Shaft
Ratio Range	1:1
Housing Height (in)	5.625 in
Reduction	Single
Housing Width (in)	7.25 in
Housing Dimensions	(L)8.71875 x (H)5.625 x (W)7.25
Housing Length (in)	8.71875 in
Output Shaft Direction	Double
Output Torque Range (in-lb)	1000 to 2500 in lbs in/lbs
Output Shaft	Shaft
Output Torque Rating (in-lb)	1650 in/lbs
Housing Material	Cast Iron
Gear Drive Size	600

General Specifications

UPC	662798006147
Weight	43.00 LB
Packaged Length	13.25 IN
Packaged Width	12.50 IN
Packaged Height	7.50 IN
HTC	8483.40.5050
Country of Origin	United States of America
