• Modular Design
• Universal Mounting Dimensions
• Increased thermal capacity and Increased efficiency
• Cast iron housing
• Alloy shafting
• Viton® seals

Technical Specifications

Output RPM	175
Input Diameter (in)	0.625 in
Frame Size	56C
Product Type	RIGHT ANGLE
Output Diameter (in)	1.250 in
Style	R
Model Code	266
Series Code	260PCX
Product Line	POWERCUBEX WORM GEAR DRIVE
Input HP	5
Ratio	10:1
Gear Type	Worm
Service Factor	1
Ratio Range	10:1
Input Style	C-Face Quill
Motor Frame Size	56C
Center Distance (in)	2.63
Output Torque Rating (in-lb)	1485 in/lbs
Output Shaft	Hollow Bore
Housing Material	Cast Iron

General Specifications

UPC	662961817075
Weight	43.00 LB
Packaged Length	12.00 IN
Packaged Width	10.00 IN
Packaged Height	11.00 IN
