• Rugged cast iron housing
• Universal Mounting Dimensions
• Spiral Bevel (SP) or Straight Bevel (ST) gearing
• Alloy shafting
• Heavy-duty industrial seals

Technical Specifications

Product Type	Right Angle
Series Code	175
Input Diameter (in)	1.000 in
Product Line	Bevel Gear Drives
Style	A,B
Service Factor	1
Maximum Input HP	16 @ 1750 RPM
Output RPM	1750
Output Diameter (in)	1.000 in
Gear Type	Spiral Bevel
Ratio	1:1
Ratio Range	1:1
Input Style	Shaft
Housing Length (in)	7.6875 in
Housing Width (in)	6.3125 in
Reduction	Single
Housing Dimensions	(L)7.6875 x (H)4.125 x (W)6.3125
Housing Height (in)	4.125 in
Output Shaft Direction	Double
Output Torque Range (in-lb)	500 to 1000 in lbs in/lbs
Output Torque Rating (in-lb)	580 in/lbs
Gear Drive Size	175
Output Shaft	Hollow Bore
Housing Material	Cast Iron

General Specifications

UPC	662798081939
Weight	25.00 LB
Packaged Length	13.25 IN
Packaged Width	12.50 IN
Packaged Height	7.50 IN
HTC	8483.40.5050
Country of Origin	United States of America
