• Rugged cast iron housing
• Universal Mounting Dimensions
• Spiral Bevel (SP) or Straight Bevel (ST) gearing
• Alloy shafting
• Heavy-duty industrial seals

Technical Specifications

Service Factor	1
Output Diameter (in)	1.000 in
Input Diameter (in)	1.000 in
Product Line	Bevel Gear Drives
Maximum Input HP	6.25 @ 1750 RPM
Input HP	6.25
Gear Type	Straight Bevel
Style	A,B
Series Code	165
Output RPM	875
Product Type	Right Angle
Ratio	2:1
Input Style	Shaft
Ratio Range	2:1
Housing Height (in)	4.125 in
Housing Width (in)	6.1875 in
Housing Dimensions	(L)7.6875 x (H)4.125 x (W)6.1875
Reduction	Single
Housing Length (in)	7.6875 in
Output Shaft Direction	Double
Output Torque Rating (in-lb)	442 in/lbs
Gear Drive Size	165
Output Torque Range (in-lb)	250 to 500 in lbs in/lbs
Housing Material	Cast Iron
Output Shaft	Shaft

General Specifications

UPC	662798004914
Weight	23.00 LB
Packaged Length	13.25 IN
Packaged Width	12.50 IN
Packaged Height	7.50 IN
HTC	8483.40.5050
Country of Origin	United States of America
