• Rugged cast iron housing
• Universal Mounting Dimensions
• Spiral Bevel (SP) or Straight Bevel (ST) gearing
• Alloy shafting
• Heavy-duty industrial seals

Technical Specifications

Output Diameter (in)	1.000 in
Product Type	Right Angle
Input Diameter (in)	1.000 in
Style	D,E
Gear Type	Spiral Bevel
Series Code	165
Service Factor	1
Product Line	Bevel Gear Drives
Maximum Input HP	16 @ 1750 RPM
Output RPM	1750
Ratio	1:1
Input Style	Shaft
Ratio Range	1:1
Housing Height (in)	4.125 in
Reduction	Single
Housing Dimensions	(L)7.6875 x (H)4.125 x (W)6.1875
Housing Width (in)	6.1875 in
Housing Length (in)	7.6875 in
Output Shaft Direction	L or R
Output Shaft	Shaft
Output Torque Rating (in-lb)	580 in/lbs
Output Torque Range (in-lb)	500 to 1000 in lbs in/lbs
Housing Material	Cast Iron
Gear Drive Size	165

General Specifications

UPC	662798004891
Weight	23.00 LB
Packaged Length	13.25 IN
Packaged Width	12.50 IN
Packaged Height	7.50 IN
HTC	8483.40.5050
Country of Origin	United States of America
