• Rugged cast iron housing
• Universal Mounting Dimensions
• Spiral Bevel (SP) or Straight Bevel (ST) gearing
• Alloy shafting
• Heavy-duty industrial seals

Technical Specifications

Product Type	Right Angle
Maximum Input HP	10.25 @ 1750 RPM
Gear Type	Spiral Bevel
Input Diameter (in)	1.000 in
Output Diameter (in)	1.000 in
Style	C,F
Series Code	150
Ratio	2:1
Product Line	Bevel Gear Drives
Service Factor	1
Output RPM	875
Ratio Range	2:1
Input Style	Shaft
Housing Height (in)	4.125 in
Housing Length (in)	6.28125 in
Housing Dimensions	(L)6.28125 x (H)4.125 x (W)6.1875
Housing Width (in)	6.1875 in
Reduction	Single
Output Shaft Direction	L or R
Gear Drive Size	150
Output Shaft	Shaft
Housing Material	Cast Iron
Output Torque Rating (in-lb)	736 in/lbs
Output Torque Range (in-lb)	500 to 1000 in lbs in/lbs

General Specifications

UPC	662798004716
Weight	20.80 LB
Packaged Length	13.25 IN
Packaged Width	12.50 IN
Packaged Height	7.50 IN
HTC	8483.40.5050
Country of Origin	United States of America
